| Voltage and Frequency | AC90 - 250V, 50 - 60HZ |
| Operating System | Linux operating system |
| CPU and Memory | I5 CPU, 4G memory, built - in solid state drive 120G |
| DMX Ports | 6 DMX output ports, 1 composite DMX input port (can be set as output) |
| Connection with NPU | Connect with NPU to support up to 65536 channels |
| Touch Screens | Built - in 2 electric lift 15.4 - inch industrial full - view touch screen, 1 9 - inch touch screen |
| USB Ports | Built - in 1 USB port dedicated for 18w fast charging mobile phone charging, 5 USB ports, 1 backup USB access port |
| Electric Playback Faders | 15 electric playback faders with induction function (60mm), 50 program keys |
| Master Control and Dimming | 1 master control push rod, 1 dimming wheel |
| Trackball | 1 controllable XY axis high - precision imported trackball |
| Electric Putters | 2 A/B field electric putters (100mm) |
| Encoders | 6 imported industrial grade wear - resistant encoders (with Push function) |
| Ethernet Ports | 2 Gigabit Ethernet ports, support MA NET, ARTNET and other signals |
| DVI Ports | 2 DVI ports, can expand two displays |
| MIDI Interface | MIDI input and output interface |
| Drawer and Keyboard | Built - in 1 drawer, built - in yellow backlit mechanical keyboard (backlight brightness adjustable) |
| UPS | Built - in high - power UPS uninterruptible power supply |
| Function Support | Support RDM function |
