Light Source: High brightness Platinum lamp OSRAM Life Span: 1500-2000 hours Color System: Use imported high temperature resistant color filters, 14pcs colors+open, half colors and rainbow effect Gobo System: 17pcs gobos+open Focusing System: Double enhanced stepping motor, electric focus Frost System: High temperature resistant frost filter, can be use as wash light Lamp On/Off Function: Lamp on/off controlled via DMX512 controller, lamp on/off while power on can be set via display Dimmer: 0-100% linear dimmer Beam Angle: Can be adjust via different gobos Prism System: 16-facet prism, bi-directionally rotating at variable speed, marco function Display: LCD screen Pan/Tilt: Use 3-phase waterproof motors for Pan & Tilt, Pan-540°, Tilt-210°, fast and stable movement, automatic pan/tilt position correction Heat Dissipation System: Use CFD software to analyze heat flux, with low noise heat dissipation system, use an imported thicken eddying fan and an imported 8*8 DC fan for the lamp heat dissipation, use an imported 12*12 DC fan to circulate heat dissipation inside the light body. Passed the test over 40° working environment(Required lamp temperature≤380°, actually, the lamp temperature≤380°). Use two 6*6 imported DC fans blowing power supply and light board at the basement. Power Supply Module Design: Power supply is from Chinese famous supplier, imported light board, which make light fixture working more stable and smoothly DMX Channel: 14CH , channel modes can be set via display, 16CH is factory setting Built-In Programme: Kinds of built-in programme, single white beam scanning from left to right at low speed or with color changing or with different light beams. Programming: You can programming six different programme via display, max.20 steps for each programme, with master/slave mode Waterproof Safety Grade: IP65 Fixture Dimension: L500*W400*H710mm/L19.69*W15.75*H27.96in Net Weight: 35Kg
