| Parameter | Specification |
|---|---|
| Pixel Pitch: | 3.91 mm |
| Module Size: | 250 × 500 mm |
| LED Screen Size: | 500 × 1000 mm |
| Module Resolution: | 64 × 64 pixels |
| LED Screen Resolution: | 128 × 128 pixels |
| Pixel Density: | 65,536 pixels/m² |
| PCB: | 2-layer board, 1.6 |
| LED Lamp Bead Model: | Mulinsen |
| Driver IC Model: | SM16380 |
| Scanning Method: | 16s |
| Refresh Rate: | 3840 Hz |
| Brightness: | 500 cd/m² |
| Standard Receiving Card: | NOVASTAR MRV208-1 |
| Standard Power Supply: | 110V–220V |
| Parameter | Specification |
|---|---|
| Pixel Pitch: | 3.91 mm |
| Module Size: | 250 × 500 mm |
| LED Screen Size: | 500 × 1000 mm |
| Module Resolution: | 64 × 64 pixels |
| LED Screen Resolution: | 128 × 128 pixels |
| Pixel Density: | 65,536 pixels/m² |
| PCB: | 2-layer board, 1.6 thickness |
| LED Lamp Bead Model: | Mulinsen |
| Driver IC Model: | SM16380 |
| Scanning Method: | 16S |
| Refresh Rate: | 3840 Hz |
| Brightness: | 3500 cd/m² |
| Standard Receiving Card: | NOVASTAR MRV208-1 |
| Standard Power Supply: | 110V–220V |
